This Car lift electro-hydraulic lift operation is designed to work with vehicles of medium and small size with a maximum total weight of 4t in garage…
+ More info
This Car lift electro-hydraulic lift operation is designed to work with vehicles of medium and small size with a maximum total weight of 4t in garages and workshops.
FUNCTIONS AND FEATURES EQUIPMENT.
• The car lift complies with Directive 2006/42 / EC and includes the latest required standards such as EN 1493: 2010.
• Designed based on the standards of quality and performance to meet the necessary requirement of any garage or workshop.
• Automatic electromagnetic safety system equipped with two anchor points in each column.
• Powered by two hydraulic cylinders.
• Panel fully automatic electric control.
• System security cable elevation.
• Automatic safety anchor arm.
• Steel cable for stability arms team.
• Platform wide base for extra support.
• Available in 380 V (three-phase) and 220 V (single phase) depending on customer demand.
• Painting with corrosion resistant finish
• The car lift is provided without any liquid.
• Regulations and European approvals.
TECHNICAL CHARACTERISTICS
|
Current magnitude |
220v 50Hz/ 380v 50Hz |
|
Power |
2.2 Kw |
|
Load capacity |
4.000 Kg |
|
System Type |
Hydro electric |
|
Type release |
Automatic |
|
Maximum lifting height |
1.928 mm |
|
Overall height |
2.866 mm |
|
Rise time |
<55 s |
|
Drop time |
>45 s |
|
Width between columns |
2.750 mm |
|
Overall width |
3.477 mm |
|
Noise level |
< 80 db(A) |
|
Weight |
685 kg |
