Automatic Tire Changer with Articulated Arm 380V

€1,815.00
Tax included
€1,500.00 Tax excluded
10/EQT-326-380
13
Quantity

EQT Professional Series

Automatic Tire Changer with Articulated Arm 380V (Model EQT-326-380)

The EQT-326-380 automatic tire changer with tilt-back articulated arm is a heavy-duty professional solution designed to streamline workflow in auto repair shops, tire centers, and fast-fit service bays. Powered by a 380V three-phase system, it delivers superior precision, speed, and safety when servicing passenger car, van, and light commercial vehicle tires.

Rim Capacity
10" - 24"
Inner 12-24" | Outer 10-21"
Power Supply
380V (3-Phase)
Motor Rating: 1.1 kW
Dimensions / Weight
960 × 760 × 920 mm
Approx. Total Weight: 220 kg
Working Pressure
8 - 10 bar
Max Wheel Width: 355 mm (14")

Key Features and Equipment Highlights

Automatic Tilt-Back Column Arm Pneumatically tilting rear column featuring position locking to speed up high-volume operations.
Heavy-Duty Self-Centering Turntable Hardened steel clamping jaws providing secure grip from 10" up to 24" across various wheel types.
380V Three-Phase Motorization High-torque reduction gearbox designed for low noise emission (<70 dB) and continuous workshop duty.
Powerful Pneumatic Bead Breaker Pneumatic cylinder equipped with plastic covers to protect delicate alloy wheels during bead unseating.

Official Technical Specifications

Technical ParameterOfficial Value
Model EQT-326-380
Reference / EAN 10/EQT-326-380 | 8436610712149
Power Supply 380V (3-Phase)
Motor Power 1.1 kW
Clamping Outer / Inner 10" - 21" / 12" - 24"
Maximum Wheel Width 355 mm (14")
Working Air Pressure 8 - 10 bar
Machine Dimensions 960 × 760 × 920 mm
Approximate Weight 220 kg
Noise Level < 70 dB

Recommended Applications

  • Automotive repair shops and fast-fit service centers.
  • High-turnover tire shops and commercial tire fitters.
  • Standard and low-profile alloy wheel mounting/demounting.
  • Light commercial vans, SUVs, and passenger car service.

Installation Requirements

Proper installation requires a 380V three-phase electrical outlet protected by an appropriate circuit breaker, along with a stable compressed air supply providing 8 to 10 bar pressure. The equipment must be anchored to a solid, level concrete floor to ensure operational stability and safety.
