Desmontadora de ruedas semiautomática

€2,117.50
Tax included
€1,750.00 Tax excluded
10/EQT-326IT-220
0
Quantity
Out-of-Stock


EQT Professional Series

Automatic Tire Changer with Articulated Arm & Tubeless Inflation Tank 220V (Model EQT-326IT-220)

The EQT-326IT-220 automatic tire changer features a tilt-back column arm and an integrated air blast bead-seating system (Tubeless IT). Operating on standard 220V single-phase power, it provides rapid, reliable, and effortless servicing for passenger cars, vans, and light commercial vehicles.

Rim Capacity
10" - 24"
Inner 12-24" | Outer 10-21"
Power Supply
220V (Single-Phase)
Motor Power: 1.1 kW
Dimensions / Weight
960 × 760 × 920 mm
Approx. Weight: 235 kg
Pressure / IT System
8 - 10 bar
Built-in Air Blast Tank (IT)

Key Features and Equipment Highlights

Integrated IT Rapid Bead-Seating System High-impact air blast through turntable clamps for instant seating of tubeless tires.
Automatic Tilt-Back Column Arm Pneumatic rear column tilt with pneumatic locking mechanism for maximum workflow efficiency.
220V Single-Phase Standard Power Supply Easy electrical setup compatible with standard 220V workshop outlets without needing 380V lines.
Alloy Wheel Plastic Protection Kit Complete plastic protector set for clamping jaws and demount head to prevent rim scratching.

Official Technical Specifications

Technical ParameterOfficial Value
Model EQT-326IT-220
Reference / EAN 10/EQT-326IT-220 | 8436610712316
Power Supply 220V (Single-Phase)
Motor Power 1.1 kW
Rapid Bead-Seating System Yes, integrated air blast tank (IT)
Clamping Outer / Inner 10" - 21" / 12" - 24"
Maximum Wheel Width 355 mm (14")
Working Air Pressure 8 - 10 bar
Machine Dimensions 960 × 760 × 920 mm
Approximate Weight 235 kg
Noise Level < 70 dB

Recommended Applications

  • Professional workshops with standard 220V electrical supply.
  • Tire service shops requiring rapid pneumatic bead seating.
  • Low-profile tubeless tire mounting on alloy wheels.
  • Maintenance of tires for passenger cars, SUVs, and light commercial vehicles.

Installation Requirements

Requires connection to a 220V single-phase electrical outlet protected by a circuit breaker, and a constant 8 to 10 bar compressed air supply to power the pneumatic functions and the IT blast tank. The unit should be mounted on a solid, level concrete floor.
