2-post car lift 5 tons

€3,146.00
Tax included
€2,600.00 Tax excluded

Car lift with electro-hydraulic lifting system, designed to operate with small and medium-sized vehicles with a maximum total weight of 5 tons in garages and workshops.

+ More info
10/EQT-T50E-220
6
Quantity

PROFESSIONAL VEHICLE LIFT · 5 TONNES

5 Tonne Two-Post Car Lift 220 V EQT-T50E-220

Professional electrohydraulic two-post vehicle lift with a 5,000 kg lifting capacity and a 220 V single-phase power supply. Designed for automotive workshops, tyre service centres and fast-fit businesses working with passenger cars, large SUVs, vans and light commercial vehicles. Equipped with two hydraulic cylinders, automatic lock release, electromagnetic safety locking, lifting arm locks and a fully automatic electrical control panel. A high-capacity solution for professional maintenance and repairs without requiring three-phase power.

MAXIMUM CAPACITY
5,000 kg
5 tonne lifting capacity
POWER SUPPLY AND MOTOR
220 V
Single-phase · 50 Hz · 3.0 kW
MAXIMUM LIFTING HEIGHT
1,945 mm
Overall height: 2,850 mm
LIFTING TIME
< 45 s
Lowering time: > 45 s

Key features and equipment

✓
5 tonne capacity for professional workshops: provides a higher load rating than conventional 4 tonne lifts. Suitable for passenger cars, large SUVs, off-road vehicles, vans and compatible light commercial vehicles, subject to approved lifting points and weight distribution.
✓
Dual hydraulic cylinders and stability system: electrohydraulic lifting powered by two cylinders, with a safety cable and steel cable contributing to synchronisation and stability during operation.
✓
Automatic release and electromagnetic safety: features two safety locking points per post, automatic lock release and a retention system designed for professional vehicle lifting operations.
✓
Automatic lifting arm locks and limit switch: arm locking devices help maintain the correct vehicle support position. The limit switch restricts travel for additional protection.
✓
Automatic controls and durable finish: 3.0 kW motor, fully automatic electrical controls, door protection pads, corrosion-resistant paint and European compliance stated in the product listing.

Technical specifications

SpecificationValue
Model EQT-T50E-220
Reference 10/EQT-T50E-220
Lift type Two-post lift with floor crossbeam
Operating system Electrohydraulic
Maximum lifting capacity 5,000 kg
Power supply 220 V single-phase · 50 Hz
Motor power 3.0 kW
Maximum lifting height 1,945 mm
Overall height 2,850 mm
Overall width 3,620 mm
Published width between posts 3,000 mm
Lifting time Less than 45 seconds
Lowering time More than 45 seconds
Noise level Below 70 dB(A)
Machine weight 1,000 kg
Hydraulic cylinders 2
Lock release Automatic
Safety system Automatic electromagnetic
Safety locking points 2 per post
Arm locking Automatic
Lifting system Safety cable and steel stabilising cable
Control panel Fully automatic electrical
Limit switch Included
Vehicle door protection Included
Finish Corrosion-resistant paint
Compliance European standards stated by supplier
Hydraulic oil Not included
Applications Passenger cars, large SUVs, vans and compatible light commercial vehicles

Recommended applications

  • General mechanical repairs and underbody work.
  • Servicing passenger cars, large SUVs and off-road vehicles.
  • Maintenance of compatible vans and light commercial vehicles.
  • Oil changes and scheduled servicing.
  • Brake inspection and repair.
  • Tyre replacement and wheel maintenance.
  • Steering and suspension diagnostics and repairs.
  • Underbody inspections and fast-fit operations.

Installation and commissioning

The lift requires a compatible 220 V, 50 Hz single-phase electrical supply and an electrical installation rated for a 3.0 kW motor. Install on a level surface using suitable anchors in accordance with the manufacturer's instructions.

Overall dimensions are 3,620 mm wide and 2,850 mm high. Check the installation drawing for usable clearances, vehicle access and the overhead space required for lifting.

Supplied without hydraulic oil. Confirm the correct fluid type and quantity in the manufacturer's installation instructions before commissioning.

The machine weighs 1,000 kg. Suitable equipment and qualified personnel are required for unloading, handling, installation, anchoring and safety checks. Floor strength must meet the manufacturer's requirements.
