This electro-hydraulic lift operation is designed to work with vehicles of medium and small size with a maximum total weight of 4t in garages and wo…
+ More info
This electro-hydraulic lift operation is designed to work with vehicles of medium and small size with a maximum total weight of 4t in garages and workshops.
FUNCTIONS AND CHARACTERISTICS OF EQUIPMENT:
• The car lift complies with Directive 2006/42 / EC and includes the latest required standards such as EN 1493: 2010.
• Designed based on the standards of quality and performance to meet the necessary requirement of any garage or workshop.
• Automatic electromagnetic safety system equipped with two anchor points in each column.
• Powered by two hydraulic cylinders.
• Panel fully automatic electric control.
• System security cable elevation.
• Automatic safety anchor arm.
• Steel cable for stability arms team.
• Available in 380 V (three-phase) and 220 V (single phase) depending on customer demand.
• Painting with corrosion resistant finish
• Regulations and European approvals.
The car lift is provided without any liquid.
TECHNICAL CHARACTERISTICS:
|
Feeding |
220v 50Hz/ 380v 50Hz |
|
Power |
2.2 Kw |
|
Loading Capacity |
4.000 Kg |
|
System Type |
Eléctrico hidráulico |
|
Tipo de desbloqueo |
Automático |
|
Maximum lift height |
1.800 mm |
|
Total height |
2.826 mm |
|
Rise time |
<30s |
|
Lowering time |
>26s |
|
Width between columns |
2.750 mm |
|
Overall width |
3.324 mm |
|
Noise level |
< 80 db(A) |
|
Weight |
610 kg |
REQUIREMENTS
The installation of this equipment should be in a perfectly level.
NOTE
The customer agrees to dispose of the material appropriate for the download of this special machinery safely.
