This Car lift electro-hydraulic lift operation is designed to work with vehicles of medium and small size with a maximum total weight of 4t in garage…
+ More info
This Car lift electro-hydraulic lift operation is designed to work with vehicles of medium and small size with a maximum total weight of 4t in garages and workshops.
FUNCTIONS AND FEATURES EQUIPMENT.
• The car lift complies with Directive 2006/42 / EC and includes the latest required standards such as EN 1493: 2010.
• Designed based on the standards of quality and performance to meet the necessary requirement of any garage or workshop.
• Automatic electromagnetic safety system equipped with two anchor points in each column.
• Powered by two hydraulic cylinders.
• Panel fully automatic electric control.
• System security cable elevation.
• Automatic safety anchor arm.
• Steel cable for stability arms team.
• Platform wide base for extra support.
• Available in 380 V (three-phase) and 220 V (single phase) depending on customer demand.
• Painting with corrosion resistant finish
• The car lift is provided without any liquid.
• Regulations and European approvals.
TECHNICAL CHARACTERISTICS
|
Current magnitude |
220v 50Hz/ 380v 50Hz |
|
Power |
2.2 Kw |
|
Load capacity |
4.000 Kg |
|
System Type |
Hydro electric |
|
Type release |
Automatic |
|
Maximum lifting height |
1.928 mm |
|
Overall height |
2.866 mm |
|
Rise time |
<55 s |
|
Drop time |
>45 s |
|
Width between columns |
2.750 mm |
|
Overall width |
3.477 mm |
|
Noise level |
< 80 db(A) |
|
Weight |
685 kg |
NOTE
The customer agrees to dispose of the appropriate materials for the media to download this special machinery safely.
Not responsible for reservations to the download you can have the carrier.
Oil drainage tank for collecting all auto oils, agriculture, etc ....
Volumen total 90 litros
Air pressure: 0.5 bar
Weight 35 Kg
Capacity 0.5 Tons
Min.length 113.5 cm
Max.length 201 cm
Length stem 80 cm
Weight: 32 kg
Mobile Scissor Lift
Safety features:
This Car lift electro-hydraulic lift operation is designed to work with vehicles of medium and small size with a maximum total weight of 4t in garage…
Simple and elegant design. Advanced technology at the service of the professional
Professional 3D Wheel Aligner – Model EQT-5555U-220
Optimize your workshop's efficiency and profitability with this high-precision 3D wheel alignment system. Designed to provide instant and reliable geometric readings for passenger cars and light commercial vehicles, it features advanced dual digital camera technology and high-resistance passive targets. Operating on a 220V single-phase power supply, it easily adapts to any standard electrical installation without the need for three-phase power. A robust, precise, and durable tool engineered for daily use in demanding workshop environments.
Embedded scissor lift
Safety features:
Precision safety locks, synchronized hydraulic cylinder system...
2-post 6-ton clear-floor car lift 380V, designed for professional workshops that need to raise heavy vehicles with safety, stability, and comfort. Its clear-floor structure facilitates easy passage between posts and improves access to the underside of the vehicle, while the electro-hydraulic system, electric safety release, and automatic safety locks allow technicians to work with confidence during mechanical, maintenance, tire, brake, suspension, and underbody inspection operations. A robust solution for workshops servicing large SUVs, vans, and light commercial vehicles.
Surface-mounted scissor lift
Safety features:
Precision safety locks. Synchronized hydraulic cylinder system…
Weight: 950 kg
The lift is supplied without any type of fluid
It can be used for lifting with: ratchet, crank, or impact gun
Dimensions 1…
2-post clear-floor car lift with overhead gantry, 220V, and 6-ton capacity, designed for professional workshops that need to lift heavy vehicles with safety, stability, and ease of use. Its clear-floor design allows smooth movement between posts and improves access to the vehicle's undercarriage, while the electro-hydraulic system, electrical safety lock release, and automatic safety locks let you work with confidence during mechanical repairs, maintenance, tire changes, brakes, suspension, and underbody inspections. A robust solution for workshops handling large SUVs, vans, and light commercial vehicles.
Portable single scissor lift 3 tons
Safety Features:
Precision safety locks, synchronized hydraulic cylinder system…
This car lift operates electro-hydraulically and is designed to work with medium and small-sized vehicles in garages and workshops.
Central lift jack 3 T
Safety features:
Telescopic arm stroke length: Max. 1600 mm
Lifting tray height…
Pneumatic Scissor Lift
Safety Features:
This car lift operates electro-hydraulically and has been designed to work with medium and small-sized vehicles with…
