Tyre changer basic
The LC810 is a tire changer, designed to mount and dismantle touring wheels, van and motorcycle.
Adaptadores para llantas de moto puestos en la fo…
LC810-380 - Basic Desmontadora car
CB910GB-220 - Wheel Balancer Basic Simple
PL230 - Right arm help LC810
LC810-380 - Basic Desmontadora car
CB910GB-220 - Wheel Balancer Basic Simple
PL230 - Right arm help LC810
LC810-380 - Basic Desmontadora car
The LC810 is a tire changer, designed to mount and dismantle touring wheels, van and motorcycle.
Adaptadores para llantas de moto puestos en la fotos NO incluídos en el precio Ref: 10/C-M-0100000 195 € + IVA
FUNCTIONS AND CHARACTERISTICS OF THE EQUIPMENT:
Feeding |
110 V/ 220 V/ 380 V |
Power |
0.75/1.1 Kw |
Outer claw |
10-18 " |
Inner claw |
12-21 " |
Maximum tire diameter |
960 mm |
Rotation speed of the turntable |
6.5 rpm |
Width of wheel |
3-12 " |
Work pressure |
8-10 bar |
Noise level |
≤ 70 db(A) |
Weight |
180 Kg |
CB910GB-220 - Wheel Balancer Basic Simple
Balancing wheels thanks to Italian engineering software.
Automatic measurement system and Dissidia and Distance inputs, with 5 ALU modes and 2 intelligent ALU modes. With wheel optimization mode and split wheel and function (Hidden weight).
Standard axle 36 mm that can work with standardized balancing accessories, international thread. Main shaft flange and threaded shaft threads that have been processed through the supersonic cooling treatment. It is durable and resistant.
Motorcycle balance adapter kit. Optional, is available. With the balance mode of the motorcycle.
Easy-to-operate calibration, which can restore machine accuracy quickly.
With standard USB port. It is convenient to update the latest software.
Display Type: LED.
With a pedal design, when fastened or glued to weight with more precision.
With power save mode, the machine enters standby mode automatically if the machine is not in use after 5 minutes.
TECHNICAL CHARACTERISTICS
Diameter of edge 10-24 "
Weight max. 65 kg wheel
Max. Wheel diameter 1,100 mm
Edge Width 1.5-20 "
Rotation speed 200 rpm
Balancing Accuracy ± 1g
Motor power 0,25 kW
Weight 110 kg
PL230 - Right arm help LC810
The PL230 is a tool that dramatically reduces the effort required to Tire low alloy wheels and high performance profile.
It is designed and manufactured to be installed in our tire changer for wheels referecnia: LC810.
Help changing low profile and Run Flat Tyres.
